GAS LINE

This high-purity gas line adopts smooth treated seamless metal tubes, orbital welded in cleanrooms with all-metal leak-proof joints. Optional double jacket & heat tracing fit hazardous gas. For semiconductor, optoelectronic fabs, it serves etching, deposition processes, conveying bulk inert, pyrophoric, corrosive and MO carrier gases.

Home Process Tools GAS TOOLS GAS LINE
Background
Integrated Complex Equipment
Background Equipment

Characteristics

  • ◆ Manufactured from high-purity seamless metal tubing with ultra-smooth inner surface treatment to minimize particle retention and gas adsorption
  • ◆ Full orbital welding construction completed inside high-grade cleanrooms with dedicated deoxidation and precision cleaning processes
  • ◆ Integrated all-metal sealing connection structure with ultra-low leakage rate to avoid secondary contamination from polymer gaskets
  • ◆ Modular prefabrication scheme with customized anti-collision fixtures and standardized welding tooling for stable consistent quality
  • ◆ Optional double containment jacket structure and heat tracing assembly for high-risk or constant-temperature gas delivery

Applications

Application Background
◆ Semiconductor wafer fabrication factories
◆ Third-generation semiconductor epitaxy production workshops
◆ LED, Micro LED and optoelectronic component manufacturing lines
◆ Flat-panel display and photovoltaic cell production plants

Suitable Occasions

Nitrogen

Whole gas delivery network linking gas cabinets, VMB and process equipment

Nitrogen

High-purity gas supply pipelines for deposition, etching and ion implantation processes

Nitrogen

Hazardous pyrophoric, toxic and corrosive specialty gas transmission routes

Nitrogen

Pre-purging, vacuum foreline and gas circulation auxiliary pipeline zones

Suitable for Fluids

Application Background
◆ Ultra-high purity bulk inert gases: N₂, Ar, O₂, H₂ and clean dry air
◆ Pyrophoric & doping electronic specialty gases: silane, phosphine, germane
◆ Corrosive process gases: chlorine, hydrogen bromide, hydrogen chloride
◆ Carrier gases for organometallic MO source vapor delivery
