FILLING SYSTEM

This modular cylinder filling system features oil-free air-driven boosters and non-weld stainless steel pipelines with adjustable pressure. It supports automated batch filling, residual gas recovery and 6N high-purity mixed gas formulation, suitable for semiconductor, medical and industrial gas plants.

Background

Integrated Complex Equipment

Background

Equipment

Characteristics

◆ Modular integrated gas filling unit built with stainless steel and aluminum alloy structure
◆ Air-driven single-acting booster pump with exhaust cooling design for stable pressurization
◆ Full non-weld pipeline connections for easy disassembly, repeated assembly and leak prevention
◆ Constant-temperature filling framework supporting semi-automatic and fully automatic operation modes
◆ Scalable layout that can be implemented in phases to match diversified production capacity demands

Main Features

Feature 1

Stepless adjustable pressure and continuous stable gas output, oil-free driving for high-purity media

Feature 1

Explosion-proof air-driven design with imported premium sealing components for long service life

Feature 1

Station-based filling structure supporting batch cylinder loading, high efficiency and small footprint

Feature 1

Built-in buffer tank with residual gas recovery to cut raw material waste

Feature 1

Multi-component mixed gas proportional distribution, capable of producing ultra-high purity gas up to 6N grade

Feature 1

Intelligent cylinder asset tracking, mechanized operation to reduce labor intensity and cylinder damage rate

Applications

Application Background

◆ Special gas manufacturing enterprises

◆ Semiconductor & electronic material factories

◆ Medical gas production workshops

◆ New energy, welding and industrial gas supply plants

Suitable Occasions

Nitrogen

Mass cylinder filling and cylinder-to-cylinder gas transfer stations

Nitrogen

Production lines for high-purity single gas and multi-component mixed specialty gas

Nitrogen

Standardized filling workshops requiring constant temperature and high safety standards

Nitrogen

Large-scale gas factories and small-batch decentralized filling sites

Suitable for Fluids

Application Background

◆ Common industrial gases: nitrogen, oxygen, hydrogen, compressed air

◆ High-purity electronic specialty gases

◆ Multi-element mixed process gases

◆ Liquefied industrial gases with stable physical properties
