VMP

VMP is an open-frame low-cost gas manifold for inert & low-risk gas distribution. It adopts exposed metal panel layout with check valves and pressure gauges, supporting manual or semi-auto control for basic flow splitting. Ideal for semiconductor labs, small pilot lines and well-ventilated gas zones, it delivers N₂, Ar, He and clean dry compressed air without enclosed cabinet or active leak protection.

Home Facility SGDS VMP
Background
Integrated Complex Equipment
Background Equipment

Characteristics

  • ◆ Open-frame panel gas distribution unit without enclosed cabinet and forced ventilation structure
  • ◆ Cost-effective simplified design dedicated to inert and low-hazard process gas delivery
  • ◆ Exposed layout with valves, pressure gauges and pipe fittings mounted directly on metal base plate
  • ◆ No active leakage protection, only equipped with basic passive gas safety components
  • ◆ Supports manual or semi-automatic operation with basic flow split function

Main Features

Feature 1

Simple mechanical structure for basic gas shunting and pressure regulation

Feature 1

Low overall cost with fewer functional modules for budget-friendly deployment

Feature 1

Equipped with standard check valves and pressure gauges for basic pipeline monitoring

Feature 1

Flexible layout design, easy to install, maintain and expand on-site

Feature 1

Manual switching control with optional semi-automatic auxiliary components00

Applications

Application Background
◆ Semiconductor small-scale pilot production lines
◆ Optical fiber and display laboratory research platforms
◆ General precision electronic manufacturing workshops
◆ University and institute advanced material labs

Suitable Occasions

Nitrogen

Laboratory auxiliary inert gas supply systems

Nitrogen

Small-batch low-risk process production lines

Nitrogen

Technical corridors with low safety risk standards

Nitrogen

Areas near gas cylinder storage with well-ventilated environment

Suitable for Fluids

Application Background
◆ Inert high-purity process gases
◆ Nitrogen (N₂), Argon (Ar), Helium (He)
◆ Clean dry compressed air (CDA) and other non-toxic, non-flammable low-risk industrial gases
