HEATING BLOCK

Heating Block preheats gas upstream of pressure regulators to compensate for Joule-Thomson cooling, preventing condensation and icing. It features a compact design, 6-meter heating pipeline, dual over-temperature protection, and quick-connect fittings for easy installation.

Home Facility CAC HEATING BLOCK
Background
Integrated Complex Equipment
Background Equipment

Characteristics

  • ◆ Compact and aesthetic design, suitable for installation in small spaces
  • ◆ Features a 6-meter heating pipeline to ensure stable and sufficient heating performance
  • ◆ Dual over-temperature protection switch design for safety
  • ◆ Electrical circuit and piping use quick-connect fittings for easy assembly and disassembly
  • ◆ Available in multiple specifications with varying power ratings (600W, 1200W, 2400W) and pipe sizes (3/8", 1/2")
  • ◆ Operates at 220V with over-temperature protection set at 65°C or 100°C

Main Features

Feature 1

Gas preheating module installed upstream of pressure regulators

Feature 1

Compensates for gas temperature loss caused by the Joule-Thomson effect during pressure reduction

Feature 1

Prevents condensation and icing on pressure regulators and related components

Feature 1

Quick-connect fittings for easy installation and replacement

Feature 1

Dual over-temperature switches provide self-protection

Applications

Application Background
◆ Semiconductor and electronics manufacturing processes
◆ Industries using gas pressure regulators in gas distribution systems
◆ Processes requiring stable gas temperature control after pressure reduction

Suitable Occasions

Nitrogen

Gas heating applications upstream of pressure regulators

Nitrogen

Scenarios where gas temperature drops significantly during pressure reduction

Nitrogen

Environments at risk of condensation or icing on gas components

Suitable for Fluids

Application Background
◆ Gases that experience temperature drop due to the Joule-Thomson effect during pressure reduction
◆ Specialty gases requiring preheating to prevent condensation and icing in gas distribution systems
